Adaptation projects offer a great way to extend the SAP standard apps. This blog gives an introduction about what requirements have to be met, and it should also serve as a cheat sheet for developers. Thus, the blog is split up into two main sections. The first one ensures feasibility whereas the second part focuses more on the development side of an adaptation project.

Feasibility of an Adaptation Project

Adaptation Project

Adaptation Projects are used to meet customer requirements in SAP Standard Apps. Examples can be adding custom behavior which will be invoked by pressing an added button to the standard app.
Be aware that not every standard app delivered by SAP can be extended with an adaptation project. Only the apps which are developed with SAP UI5 can be extended this way. In the Fiori apps library, it is easy to determine the developing language of the app.

Once the criteria are met and the app can be extended with an adaptation project the visual editor comes into place. The visual editor is integrated into the SAP Business Application Studio (SAP BAS) which allows the user to adjust the properties of the standard app as well as to add custom controls and logic. To do so rightclick on the area which should be extended and add your control or logic.
There is a safe mode that can be activated, this one should ensure that the extension will work with future system upgrades.

Make the Adaptation project visible

To test the adaptation project in the original app the launchpad customizing has to be adjusted. Therefore it is best practice to create a new mapping for the routing as well as a new tile which will then open the created variant. Hence, the standard app will still be available if in the deployed extension an error occurs. The target mapping requires the parameter sap-appvariant-id and should look like the following:

Once the target mapping is created the app variant (the adaptation project) can be called by using the # of the original app in combination with the URL parameter sap-appvar-id: #YAIFMessage-display?sap-appvar-id=customer.<namespace>

To ensure, that the adaptation project is called the inspector is required. Above the directory of the developed and standard apps there will be another directory for adaptation projects.

Debug extension

In the inspector, you then can see that a directory lrep/flex/modules which contain the extension.
In this directory, you can find the coding of your adaptation project. If this entry is not listed then it is a hint that there might be a syntax error within your extension.

Useful tools by SAP

SAP delivered some useful tools to further investigate an app. As a reminder those tools are listed with the corresponding keyboard shortcuts.

Development of an Adaptation Project

Extension coding

In the adaptation project it is possible to either override the methods of the extended controller (be careful on this one), to define your methods and execute them as well as to override the lifecycle methods of the standard app. When overriding lifecycle methods be aware that your coding in the extension will not replace the coding of the standard app – rather your coding will be called before or after the lifecycle method of the standard app. See the following picture as a demonstration.

return ControllerExtension.extend("customer.<namespace>.ExcelReport", {
    override:{
        onInit: function(oEvent){
            ...
        },
        onAfterRendering: function(oEvent){
            ...
        }
    },
    myMethod(){
      ...
    },
    anotherMethod(){
      ...
    }
})

The context of the controller extension can be retrieved via

 this.base.extension.<namespace>

(in the debugger). The context of the extented controller can be retrieved via

this.base.getView().getController()

Contexts and extension Methods

The following information lists the commands to navigate between the contexts of the controller and the extension. Hence, use the controller context of the original app as well as the context of the extension.

Context of the extension

this.base.extension.<namespace>
this.base.extension.customer.SysMsgMonitorOverview.OverviewExtension

this Context of the current controller

this.base.<variable> = 'abc'

Controller of the current view

this.base.getView().getController()

Helpfull skills

Further helpful skills which might come in handy are:

• UI5 Eventhandling

sap.ui.getCore().getEventBus().publish("YourEventChannel", "getAllData", {})
sap.ui.getCore().getEventBus().subscribe(
                        "YourEventChannel",
                        "getAllData",
                        this.getAllData,
                        this);

• Basic jQuery
  • to retrieve a control if it is available (fully rendered and with available data)
  • to automatically scroll up and down in an section

var intervalId = setInterval(
    () => {
        var oExtContext = this.base.extension.customer.namespace.OverviewExtension
        // if the cards (especially the headers) are rendered
        if ($("div[id*='cardHeader']")[0]) {
            ...
            window.clearInterval(intervalId);
        }

    },1000, this, intervalId);

Problems which can occur

• More than one extension project could be required while navigating to a detail view (check the app ID after navigating)
• If the standard app uses the OData v4 Model it can be very hard to retrieve the data which are bound to the view. Since the Model / Context methods getProperty() and getObject() are not available in the v4 Model. On a binding (get it from the view) it is possible to use the method requestObject() which then will return a promise.

await this.base.getView().byId(<id>).getBindingContext().requestObject()
    .then(function(oData) {
        ...
    })
    .catch(function(oErr) {
        ...
    })

This post is part IV of a blog series.

Read also part I: Fiori Introduction

part II: Fiori Customization

part III: Extensibility Scenario With Key User Tools

TL;DR: The Fiori cosmos has a lot of expressions. There are standard Fiori apps as well Fiori lighthouse apps available. Also, there are several options to develop our own Fiori app. In this blog we clarify some of the terms to get everybody on the same page for the upcoming blogs.

Introduction

When someone mentions Fiori he/she often refers to a Fiori standard app. Even though there is a huge Fiori world with a lot of terms. In this blog series we are digging a bit deeper into the Fiori world. We will show the differences between Fiori apps as well as how you can extend them. Either by customizing your Fiori apps or by extending them. To get things started we focus on the question what types of standard Fiori apps exist and how do they differentiate.

Since we see our blogs as an exchange of ideas, feel free to add comments as well as get in contact with us.

Fiori Introduction

To get things started I want to get all of us on the same page. Hence, we will start very basic and discuss about what Fiori is.

Fiori is/are basically design guidelines which describe how apps should look and feel. Thus, all Fiori apps should follow those design guidelines.

Beside the Fiori apps there are also the Fiori-like apps and the UI5 freestyle apps. Fiori-like apps are apps which follow the design guidelines most of the time but they have little twists which are not in the Fiori design guidelines. For example a button could have a different design or is placed on a different part of the UI where the design guidelines doesn’t intend it. Such changes occur often during development. The other option is to create a ‘UI5 freestyle app’. Those apps are not bound to the Fiori design guidelines. Hence, it is possible to create the app any way you want it. In those kind of apps we have the possibility to create our own button or a line in a table with our own design. A sample for such custom controls would be the following two pictures. This custom control is part of a todo-list. The list item will cross out the text and the due date as well as provide a green border once the task is marked as solved.

Fiori lighthouse app vs Fiori standard app

Since this blog series focuses on the Fiori standard apps, we will now take a look at the two different Fiori app types which are provided by SAP. There are the Fiori standard apps and the Fiori lighthouse apps. The lighthouse apps are also standard apps, because they are provided by SAP as well by SAP. They serve more or less as an entry point to the Fiori standard apps. Both types of apps are found in the Fiori Apps Library. The lighthouse apps will be displayed with a lighthouse in front of the name.

When we compare the Fiori standard apps and developed apps, we can quickly realize that apps which are developed by SAP are cheaper and provide customization and extension options. Whereas on the other hand a developed Fiori-like or freestyle UI5 app provides more flexibility as well as more options during the complete development process. In the upcoming blogs we will display some useful features as well as some tips and tricks to enhance a standard app. The first topic we discuss will be modifications as well as enhancements of the UI.

Read also part II: Fiori Customization

part III: Extensibility Scenario With Key User Tools

part IV:

TL;DR: With a custom-theme as well as with the key-user tools we are able to quickly make changes that our Fiori apps or our Fiori Launchpad appear in a new brilliance. With a bit more time we can start an adaption project to enhance the functionality of a Fiori app.

Introduction

This is the second post of this blog series. In this blog post I want to show you which customization options there are for Fiori apps. We will focus on the UI, since there are several interesting opportunities to modify the UI.

There are three options:

• We can create a custom-theme
• We can leverage the key-user tools to modify the UI during runtime
• We use the Web IDE or Business Application Studio to manually write a small extension via an adaptation project.

What kind of customization can users do on their launchpad?

There are several possibilites to create as well as to customize the Fiori Launchpad (FLP). With an Plug-In it is possible to add custom coding to the FLP. This might be useful to alert user of upcoming events or system downtime. With the Plugin it is also possible to add icons to the headerbar of the FLP. To do so an renderAPI has to be used within the plugin.

The Plugin can be build with the Web IDE. Sure today there will be several options to do so.

The created plugin is based on SAP UI5. Hence, it consits of an Component.js and a manifest.json file as well as the lifecycle methods of an UI5 app. With the lifecycle methods and the UI5 infrastructure we can develop our own coding. E.g. create a model and attach it to a datsource to retrieve or send data to an oData service.

If your intend is to simplay brand the FLP in a certain with (e.g. with your company colors) then there is the possibility to create a custom them, which will be discussed in the next section.

Custom-theme

The first option to modify the UI is to make use of a custom theme. To create a custom theme we use the ‘Theme Designer’. You can start the theme designer with transaction UI5/THEME_DESIGNER (important: use chrome as a browser since it doesn’t work in every browser).

The start screen of the theme designer looks like the following picture. From here you can modify or create a new theme.

When you create a new theme you will be asked to enter a link, which points to the app. Here you can enter the link of your Fiori Launchpad. By doing so all apps on the launchpad will appear in the same theme once the theme is set.

When the theme is created and built (via safe & built in the picture above) it is available on the chosen apps. All users can access it from the launchpad settings in the user menu. Moreover, it can be set as a default theme. To set a theme as the default theme on the Fiori launchpad there are further transactions. The first one is used to set a created theme as default theme for the system UI2/NWBC_CFG_CUST. The second transaction is for the administration of the themes UI5/THEME_TOOL.

Key-user tools

The key-user tools are a set of apps which provide different extensibility options. The key-user apps were developed by SAP to make extension projects easier and more cost efficient. In some parts, this works well. One example is that with the key-user tools we are able to modify the UI of an app during runtime. With the UI adaptation it is possible

• to sort sections of an app via drag and drop
• to combine fields (or split combined fields)
• to hide fields
• to change labels
• as well as to add new fields to the UI.

When you want to play around with them assign the role SAP_UI_FLEX_KEY_USER to your user and activate the ICF node /sap/bc/ui2/flp. Once this is done, you can start the key-user tools via the user menu.

P.S. we set a custom theme and hence the apps in our Fiori Launchpad look different.

The changes you’ve made can be added to a transport request and hence they can be made available for specific systems.

Adding new fields to the UI can be a bit tricky, as it depends on the fields the OData service sends to the app. If the desired field is not available in the app, the OData service has to be extended. Even though the key-user tools are a strong tool, sometimes it is not suitable and we need to manually extend the app ourselves. To do so, we will take a look at adaptation projects.

Adaptation project

Another way to customize the UI or the application logic of an app is via an adaptation project. This can be in the Web IDE or the Business Application Studio. With an adaptation project it is possible to see which extension points are available. Extension points are kind of predefined interfaces. With those extension points it is possible to quickly extend the existing app.

Another way to discover the extension points is to check the section ‘Extensibility’ in tab ‘Implementation Information’. In the section is a link to a documentation page about the different extensibility options for the specific app.

In order to extend apps this way, we have to make sure that they are developed with UI5. You can see this when you select an app in the Fiori apps library and then check the application type.

With the presented customizing options we can quickly make useful changes as well as let Fiori apps appear in our own theme. When more changes on a Fiori app are desired an adaption project might be the correct choice. In the next post we will take a look towards a more technical extensibility feature which comes handy into place when the adaption project does not provide enough extensibility features.

This post is part of a blog series.

Read also

part I: Fiori Introduction

part III: Extensibility Scenario With Key User Tools

Part IV: SAP UI5 Adaptation Project

Introduction

This is the second post of this blog series. In this blog post I want to show you which customization options there are for Fiori apps / SAP standard apps. We will focus on the UI, since there are several interesting opportunities to modify the UI.

There are three options:

• We can create a custom-theme
• We can leverage the key-user tools to modify the UI during runtime
• We use the Web IDE or Business Application Studio to manually write a small extension via an adaptation project.

Custom-theme

The first option to modify the UI is to make use of a custom theme. To create a custom theme we use the ‘Theme Designer’. You can start the theme designer with transaction UI5/THEME_DESIGNER (important: use chrome as a browser since it doesn’t work in every browser).

The start screen of the theme designer looks like the following picture. From here you can modify or create a new theme.

When you create a new theme you will be asked to enter a link, which points to the app. Here you can enter the link of your Fiori Launchpad. By doing so all apps on the launchpad will appear in the same theme once the theme is set.

When the theme is created and built (via safe & built in the picture above) it is available on the chosen apps. All users can access it from the launchpad settings in the user menu. Moreover, it can be set as a default theme. To set a theme as the default theme on the Fiori launchpad there are further transactions. The first one is used to set a created theme as default theme for the system UI2/NWBC_CFG_CUST. The second transaction is for the administration of the themes UI5/THEME_TOOL.

Key-user tools

The key-user tools are a set of apps which provide different extensibility options. The key-user apps were developed by SAP to make extension projects easier and more cost efficient. In some parts, this works well. One example is that with the key-user tools we are able to modify the UI of an app during runtime. With the UI adaptation it is possible

• to sort sections of an app via drag and drop
• to combine fields (or split combined fields)
• to hide fields
• to change labels
• as well as to add new fields to the UI.

When you want to play around with them assign the role SAP_UI_FLEX_KEY_USER to your user and activate the ICF node /sap/bc/ui2/flp. Once this is done, you can start the key-user tools via the user menu.

P.S. we set a custom theme and hence the apps in our Fiori Launchpad look different.

The changes you’ve made can be added to a transport request and hence they can be made available for specific systems.

Adding new fields to the UI can be a bit tricky, as it depends on the fields the OData service sends to the app. If the desired field is not available in the app, the OData service has to be extended. Even though the key-user tools are a strong tool, sometimes it is not suitable and we need to manually extend the app ourselves. To do so, we will take a look at adaptation projects.

Adaptation project

Another way to customize the UI or the application logic of an app is via an adaptation project. This can be in the Web IDE or the Business Application Studio. With an adaptation project it is possible to see which extension points are available. Extension points are kind of predefined interfaces. With those extension points it is possible to quickly extend the existing app.

Another way to discover the extension points is to check the section ‘Extensibility’ in tab ‘Implementation Information’. In the section is a link to a documentation page about the different extensibility options for the specific app.

In order to extend apps this way, we have to make sure that they are developed with UI5. You can see this when you select an app in the Fiori apps library and then check the application type.

With the presented customizing options we can quickly make useful changes as well as let Fiori apps appear in our own theme. When more changes on a Fiori app are desired an adaption project might be the correct choice. In the next post we will take a look towards a more technical extensibility feature which comes handy into place when the adaption project does not provide enough extensibility features.

Read also part I: Fiori Introduction

part III: Extensibility Scenario With Key User Tools

part IV: SAP UI5 Adaptation Project

Introduction

In this part of the blog series we are going to create our own business object. After the customization in the previous blogs we are going to take a look about an extensibility option which is provided by the key-user-tools – the app ‘Custom Business Objects’. With this app we are able to create a new database table, an application logic as well as an OData service within a matter of minutes. With the created OData service we can quickly create an Fiori application which we can then integrate on our Fiori Launchpad after deployment.

Create a Custom-Business-Object

In order to create a custom business object start the app ‘custom business object’ and create a new business object. After entering a name for the new object we receive the following overview (first picture).

With the different tabs we are able to set the details of the business object. When creating a new business object it is useful to set the checkbox ‘Service Generation’. By setting this checkbox an OData service, based on cds-views, will be generated. This OData service enables us to activate it in our sap system.

For the purpose of this post we activated the OData service and requested the metadata in a browser.

With the activated OData service we have several options to use the created structure to our needs. We could go the way of ‘side-by-side’ extensibility and build an app which modifies our data outside of our system. With the help of the Web IDE or Business Application Studio we can create an Fiori app, developed with either Fiori Elements or SAP UI5. For this post we chose to create the app with an Fiori Elements template in the Web IDE.

In the Web IDE we create a new project from template, choose the desired template and then use the category ‘service url’ to select the activated OData service. There is a minor prerequisite to be able to use the category ‘service url’. In your environment (cloud-foundry or neo) a connection to the source system, in which we just created the custom business object, has to be specified. If this is the case you will be able to call the OData service and it should look like something in the picture below. If you don’t have a connection setup you could either set it up or you could use one of the other two options (a custom UI5 or CAP app) to work with your data from the created business object.

Once we are done with the development we can deploy it to our system and register it on to the Fiori Launchpad. By doing so the created app will automatically appear in our theme, which we created in the last edition of the blog series.

Closing

As you can see there are several options to customize as well as to enhance the Fiori standard apps without much effort. With a bit more time it is possible to launch different types of extension projects. Let us know about your experiences with the customization and extension of Fiori standard apps!
